1)
All default values = 0 or marked as the range of values a to b
2)
Display depends on the general SD54760 $SNS_MEA_FUNCTION_MASK_PIECE
3)
Intermediate positioning, circling around the ball at the equator
4)
Measure 3 balls: The same diameter setpoint applies for all three balls (_SETV)
5)
Default value for S_TNVL=1.2
Correction in WO: Correction is only performed in the WO when the determined distortion is below the S_TNVL limit value.
6)
If WO "fine" has not been set up in MDs, correction is according to WO "coarse"
7)
For measuring variant "Measure three balls", correction in a global basic frame is not possible (S_KNUM = 3001 to 3016),
as the frame does not have a rotation component.
3.25.3.11 CYCLE995 measuring cycle parameters
PROC CYCLE995 (INT S_MVAR,INT S_KNUM,INT S_PRNUM,REAL S_SETV,REAL S_FA,REAL S_TSA,REAL
S_STA1,REAL S_INCA,REAL S_DZ,REAL S_SETV0,REAL S_SETV1,REAL S_SETV2,REAL S_TUL,REAL
S_TZL,INT S_NMSP,INT S_MCBIT,INT _DMODE,INT _AMODE)
Table 3-18 CYCLE995 call parameters
1)
No
.
Screen
form param‐
eters
Cycle pa‐
rameters
Meaning
1 S_MVAR Measuring variant (default=5)
Val‐
ues:
UNITS: Contour element
5 = Spindle geometry (parallel to the tool axis)
TENS: Repeat measurement
1 = with repeat measurement
HUNDREDS: No offset target
0 = measurement only
THOUSANDS: Measuring strategy
2 = measurement at an angle, align probe in direction of switching
TEN THOUSANDS: Number of spheres to be measured
0 = measure a sphere
HUNDRED THOUSANDS: Number of measurement points
1 = 4 measurement points when measuring at an angle (circle the sphere)
ONE MILLION: Determination of the diameter setpoint of the sphere
0 = No determination of the diameter setpoint of the sphere
1 = Determination of the diameter setpoint of the sphere
2 Selection S_KNUM Correction target
0 = 0
3 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(value range 1 to 40)
4 DM S_SETV Diameter of the calibration sphere
4)
5 DFA S_FA Measurement path
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1183
