No
.
Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
16 T S_TNAME Tool name
2)
17 DL S_DLNUM Setup additive offset DL number
1), 4)
18 TZL S_TZL Work offset
1), 2)
19 DIF S_TDIF Dimensional difference check
1), 2)
20 TUL S_TUL Upper tolerance limit (incremental to the setpoint)
2)
21 TLL S_TLL Lower tolerance limit (incremental to the setpoint)
2)
22 TMV S_TMV Offset range for averaging
1)
23 FW S_K Weighting factor for averaging
1)
24 S_EVNUM Date set, empirical value memory
1), 6)
25 S_MCBIT Reserved
26 _DMODE Display mode
Val‐
ues:
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane active before the cycle call remains active
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
27 _AMODE Alternative mode
Val‐
ues:
UNITS: Dimensional tolerance yes/no
0 = No
1 = Yes
0)
All default values = 0 or marked as the range of values a to b.
1)
Display depends on the general SD54760 $SNS_MEA_FUNCTION_MASK_PIECE
2)
Only for offset in tool, otherwise parameter = ""
3)
Only for offset in tool and dimensional tolerance "Yes", otherwise parameter = 0
4)
Only if the "Setup additive offset" function has been set-up in the general MD 18108 $MN_MM_NUM_SUMCORR .
5)
If WO "fine" has not been set up in MDs, correction is according to WO "coarse"
6)
Empirical averaging only possible for tool offset
Value range for empirical mean value memory:
1 to 20 numbers (n) of the empirical value memory, see channel-specific SD55623 $SCS_MEA_EMPIRIC_VALUE[n-1]
10000 to 200000 numbers (n) of the mean value memory, see channel-specific SD55625
$SCS_MEA_AVERAGE_VALUE[n-1]
7)
Value range of starting angle -360 to +360 degrees
8)
Value range of incremental angle >0 to ≤90 degrees for four measuring points or >0 to ≤120 degrees for three measuring
points.
3.25.3.10 CYCLE997 measuring cycle parameters
PROC CYCLE997 (INT S_MVAR,INT S_KNUM,INT S_PRNUM,REAL S_SETV,REAL S_FA,REAL S_TSA,REAL
S_STA1,REAL S_INCA,REAL S_SETV0,REAL S_SETV1,REAL S_SETV2,REAL S_SETV3,REAL S_SETV4,REAL
S_SETV5,REAL S_SETV6,REAL S_SETV7,REAL S_SETV8,REAL S_TNVL,INT S_NMSP,INT S_MCBIT,INT
_DMODE,INT _AMODE)
Work preparation
3.25 Programming cycles externally
NC programming
1180 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
