No. Parameter
mask
Parameter
internal
Data type Meaning
19 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of feedrate: G group (G94/G95) for
surface and depth feedrate
0 = Compatibility mode
1 = G command as before cycle call.
G94/G95 same for surface and
depth feedrate
HUNDREDS: Reserved
THOUSANDS: Software version identification
1 = Function extension LONGHOLE
(dimensioning of reference point)
20 <_AMODE> INT Alternative mode
UNITS: Final depth Z1 (abs/inc)
0 = Compatibility
1 = Z1 (inc)
2 = Z1 (abs)
Note
The cycle is provided with new functions that are not on earlier software versions.
Consequently certain parameters in the screen form (<NUM>, <RAD>, <INDA>) are no
longer displayed. Multiple slots on one position pattern can be programmed using "MCALL"
and calling the desired position pattern, e.g. HOLES2.
3.25.1.10 CYCLE60 – engraving
Syntax
CYCLE60(<_TEXT>, <_RTP>, <_RFP>, <_SDIS>, <_DP>, <_DPR>, <_PA>,
<_PO>, <_STA>, <_CP1>, <_CP2>, <_WID>, <_DF>, <_FFD>, <_FFP1>,
<_VARI>, <_CODEP>, <_UMODE>, <_GMODE>, <_DMODE>, <_AMODE>)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1041
