7. Wiring Data
8830
1/98
7-1
Section Contents
TITLE
BSDs
LEVEL 1 BSD
How to Use BSDs 7-2
Level 1 BSD 7-3
STANDBY POWER
1.1A Main Power On (with "Delta"
Noise Filter) (50 and 60 Hz) 7-8
1.1B Main Power On (with "Corcom"
Noise Filter) (50 and 60 Hz) 7-10
1.2 DC Power Generation 7-12
1.3 Interlock Monitoring 7-16
1.4 Machine Cooling 7-18
MODE CONTROL
2.1 Mode Selection 7-20
MACHINE RUN CONTROL
3.1 Machine Run Control 7-24
PRINT POWER
4.1 Fuser Roll Drive 7-28
4.2 Developer Drive 7-30
4.3 Drum Drive 7-32
IMAGING
6.1 Imaging (Right Side) 7-36
6.2 Imaging (Left Side) 7-38
PAPER SUPPLYING
7.1 Media Drive 7-42
7.2 Media Feed, Roll 1 7-44
7.3 Media Feed, Roll 2 7-46
7.4 Media Feed, Roll 3 7-48
7.5 Media Cutting 7-50
PAPER FEEDING
8.1 Media Registration and
Transportation 7-54
XEROGRAPHICS
9.1 Charging 7-58
9.2 Exposure 7-60
9.3 Development 7-62
9.4 Image Transfer and Media
Stripping 7-64
9.5 Drum Cleaning 7-66
9.6 Drum Discharging 7-68
9.7 Toner/Developer Dispense 7-70
9.8 Corotron and Developer Bias
Power 7-72
PRINT TRANSPORTATION AND FUSING
10.1 Fuser Heat 7-76
10.2 Fuser Oil Dispensing 7-80
10.3 Fusing and Media Exit 7-82
PLUG/JACK LIST 7-85
