Yamaha FZ6-SS - Exhaust Pipe

5-2
Order Job/Part Q’ty Remarks
1
2
3
4
5
Removing the exhaust pipe
Exhaust pipe assembly
Exhaust pipe gasket
Catalyst pipe assembly
Muffler protector assembly
Muffler
1
4
1
1
1
Remove the parts in the order listed.
For installation, reverse the removal
procedure.
20 Nm (2.0 mSkg, 15 ftSlb)
16 Nm (1.6 mSkg, 11.6 ftSlb)
20 Nm (2.0 mSkg, 15 ftSlb)
20 Nm (2.0 mSkg, 15 ftSlb)
20 Nm (2.0 mSkg, 15 ftSlb)
20 Nm (2.0 mSkg, 15 ftSlb)
20 Nm (2.0 mSkg, 15 ftSlb)
9 Nm (0.9 mSkg, 6.5 ftSlb)
34 Nm (3.4 mSkg, 26 ftSlb)
ENGINE
ENG
EAS00189
EXHAUST PIPE
