ELECTRICAL SPECIFICATIONS
SPEC
ELECTRICAL SPECIFICATIONS
Item Standard Limit
System voltage 12 V SSS
Ignition system
Ignition system type
Ignition timing
Advancer type
Crankshaft position sensor
resistance/color
T.C.I. unit model (manufacturer)
DC. T.C.I.
5_ BTDC at 1,300 r/min
Digital
248 X 372 Ω at 20_C (68_F)/Gy-B
F8T811 (MITSUBISHI)
SSS
SSS
SSS
SSS
SSS
Ignition coils
Model (manufacturer)
Minimum ignition spark gap
Primary coil resistance
Secondary coil resistance
JO383 (DENSO)
6 mm (0.24 in)
1.53 X 2.07 Ω at 20_C (68_F)
12.0 X 18.0 kΩ at 20_C (68_F)
SSS
SSS
SSS
SSS
Spark plug cap
Material
Resistance
Resin
10.0 kΩ at 20_C (68_F)
SSS
SSS
Charging system
System type
Model (manufacturer)
Normal output
Stator coil resistance/color
A.C. magneto
F5VX (MORIC)
14 V/310 W at 5,000 r/min
0.22 X 0.34 Ω at 20_C (68_F)/W-W
SSS
SSS
SSS
SSS
Rectifier/regulator
Regulator type
Model (manufacture)
Semi conductor short circuit
SH719AA (SHINDENGEN)
SSS
SSS
()
No-load regulated voltage
Rectifier capacity
Withstand voltage
()
14.1 X 14.9 V
18 A
240 V
SSS
SSS
SSS
Battery
Battery type
Battery voltage/capacity
Specific gravity
Manufacturer
Ten hour rate amperage
GT12B-4
12 V/10 Ah
1.320
GS
1.0 A
SSS
SSS
SSS
SSS
SSS
Headlight type Halogen bulb
Bulbs (voltage/wattage quantity)
Headlight
Tail/brake light
Front turn signal/position light
Rear turn signal light
Licence light
Meter light
12V 60 W/55 W 1
12 V 55 W 1
12 V 5 W/21 W 1
12 V 21 W/5 W 2
12 V 21 W 2
12 V 5 W 1
EL
SSS
SSS
SSS
SSS
SSS
SSS
SSS
