7-27
THROTTLE BODIES
FI
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Removing the injectors
Throttle position sensor coupler
Intake air pressure sensor coupler
Cylinder #1-injector coupler
Cylinder #2-injector coupler
Cylinder #3-injector coupler
Cylinder #4-injector coupler
Sub wire harness
Negative pressure hose
Intake air pressure sensor
Fuel distributor
Injector
Throttle position sensor
Fuel pulsation damper
Throttle body assembly
1
1
1
1
1
1
1
1
1
1
4
1
1
1
Remove the parts in the order listed.
Disconnect
Disconnect
For installation, reverse the removal pro-
cedure.
EAS00910
INJECTORS
To Next Page
