6-8
Order Job/Part Q’ty Remarks
1
2
3
Removing the thermostat
Seat
Front cowling inner panel (left and right)
Fuel tank
Air filter case
Coolant
Throttle body assembly
Radiator inlet hose
Thermostat cover
Thermostat
1
1
1
Remove the parts in the order listed.
Refer to “SEAT” in chapter 3.
Refer to “COWLINGS”
Refer to “FUEL TANK”
Refer to “AIR FILTER CASE” in chapter 3.
Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
Refer to “THROTTLE BODIES” in
chapter 7.
For installation, reverse the removal
procedure.
12 Nm (1.2 mSkg, 8.7 ftSlb)
THERMOSTAT
COOL
EAS00460
THERMOSTAT
To Next Page
