8-22
STARTER MOTOR
ELEC
NOTE:
5. Measure:
S brush length
a
.
Out of specification ! Replace the brushes
as a set.
Brush length wear limit
3.5 mm (0.14 in)
6. Measure:
S brush spring force
Out of specification ! Replace the brush
springs as a set.
Brush spring force
7.16 X 9.52 N
(730 X 971 gf, 25.77 X 34.27 oz)
7. Check:
S gear teeth
Damage/wear ! Replace the gear.
8. Check:
S bearing
S oil seal
Damage/wear ! Replace the defective
part(s).
EAS00772
ASSEMBLING THE STARTER MOTOR
1. Install:
S brush seat
1
2. Install:
S armature
2
S O-ring
3
New
Align the tab
a
on the brush seat with the slot
b
in the starter motor rear cover.
