5-46
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
Removing the clutch cover
Engine oil
Coolant
Coolant hose
Clutch cable
Clutch cable holder
Clutch cover
Clutch cover gasket
Dowel pin
1
1
1
1
1
2
Remove the parts in the order listed.
Drain.
Refer to “CHANGING THE ENGINE OIL”
in chapter 3.
Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
Disconnect.
Disconnect.
For installation, reverse the removal
procedure.
12 Nm (1.2 mSkg, 8.7 ftSlb)
12 Nm (1.2 mSkg, 8.7 ftSlb)
CLUTCH
ENG
: YAMAHA BOND No. 1215
EAS00273
CLUTCH
CLUTCH COVER
To Next Page
