2-1
GENERAL SPECIFICA
TIONS
SPEC
SPECIFICA
TIONS
GENERAL SPECIFICA
TIONS
Item
Standard
Limit
Model code
5VX3 (USA except for CAL)
5VX4 (CAL)
SSS
Dimensions
Overall length
Overall width
Overall height
Seat height
Wheelbase
Minimum ground clearance
Minimum turning radius
2,095 mm (82.5 in)
750 mm (29.5 in)
1,215 mm (47.8 in)
795 mm (31.3 in)
1,440 mm (56.7 in)
145 mm (5.71 in)
2,800 mm (1
10.2 in)
SSS
SSS
SSS
SSS
SSS
SSS
SSS
Weight
Wet (with oil and a full fuel tank)
Maximum load (except motorcycle)
207 kg (456 lb) (USA except for CAL)
208 kg (459 lb) (CAL)
190 kg (419 lb) (USA except for CAL)
189 kg (417 lb) (CAL)
SSS
SSS
27
29
