Yamaha FZ6-SS User Manual

2-21
TIGHTENING TORQUES
SPEC
See
NOTE 3
CHASSIS TIGHTENING TORQUES
Item
Thread
Tightening
Remarks
Item
size
Nm mSkg ftSlb
Remarks
Upper bracket pinch bolt M8 30 3.0 22
Steering stem nut M22 110 11 80
Upper bracket and upper handlebar holder M8 23 2.3 17
Under bracket pinch bolt – 30 3.0 22
Lower ring nut M25 18 1.8 13 See NOTE 1
Front fork cap bolt M35 24 2.4 17
Damper rod assembly bolt M10 23 2.3 17
Pinch bolt (front wheel axle) M8 23 2.3 17
Front brake master cylinder and master cylinder
bracket
M6 10 1.0 7.2
Front brake master cylinder cap screw M4 2 0.2 1.4
Front brake hose union bolt M10 30 3.0 22
Front brake hose holder and front fork M6 10 1.0 7.2
Front cowling stay and frame M8 33 3.3 24
Front cowling bracket and frame M6 7 0.7 5.1
Front fender and front fork M6 6 0.6 4.3
Clutch lever holder pinch bolt M6 11 1.1 8.0
Engine mount bolts (left of front side) M10 55 5.5 40
Engine mount bolts (left of rear side) M10 55 5.5 40
Engine mount bolts (right of front side) M10 55 5.5 40 See NOTE 2
Engine mount self locking nut (upper) M10 55 5.5 40
Engine mount self locking nut (lower) M10 55 5.5 40
Fornt frame and rear frame (upper) M10 41 4.1 30
Front frame and rear frame (lower) M10 41 4.1 30
Pivot shaft and frame M18 120 12 87
Rear shock absorber and frame M10 40 4.0 29
Rear shock absorber and rear arm M10 40 4.0 29
Seal guard and rear arm M6 7 0.7 5.1
Rear fender and rear arm M6 7 0.7 5.1
Rear brake hose holder and rear arm M6 7 0.7 5.1
Fuel tank bracket and frame M6 7 0.7 5.1
Fuel tank bracket and fuel tank M6 7 0.7 5.1
Fuel tank and rear frame M6 7 0.7 5.1
Fuel tank and fuel tank cap M5 6 0.6 4.3
Fuel pump and fuel tank M5 4 0.4 2.9
Ignition coil and battery box M6 7 0.7 5.1
Seat lock and frame M6 7 0.7 5.1
Rotor and mud guard M6 3 0.3 2.2
Licence plate light and flap M5 4 0.4 2.9
Front side reflector and front brake hose holder M5 4 0.4 2.9
Rear side reflector and stay M5 3 0.3 2.2
Rear reflector and flap M5 4 0.4 2.9
Flap and bracket 6 M6 7 0.7 5.1
Blacket 6 and rear frame M6 19 1.9 14
Seat handle and tail/brake right unit M6 3 0.3 2.2
Rear fender cover and seat handle M5 4 0.4 2.9
Seat handle bolt M8 23 2.3 17
Muffler and rear fender M6 7 0.7 5.1
