Yamaha FZ6-SS User Manual

2-18
TIGHTENING TORQUES
SPEC
Yamaha bond
No.1215
TIGHTENING TORQUES
ENGINE TIGHTENING TORQUES
Item
Fastener
Thread
Q
’
ty
Tightening torque
Remarks
Item
Fastener
size
Qty
Nm mSkg ftSlb
Remarks
Spark plugs – M10 4 18 1.8 13
Cylinder head Bolt M10 10 1st 19
2nd 50
1.9
5.0
14
36
Bolt M6 2 12 1.2 8.7
Camshaft caps Bolt M6 20 10 1.0 7.2
Cylinder head cover Bolt M6 6 12 1.2 8.7
Camshaft cap oil check bolt Bolt M8 1 20 2.0 15
Air indication system reed valve
cover
Bolt M6 4 10 1.0 7.2
Air-cut valve stay Bolt M6 1 10 1.0 7.2
Camshaft sprockets Bolt M7 4 20 2.0 15
Connecting rod caps (except for CAL) Nut M7 8 15 + 150_ 1.5 + 150_ 11 + 150_
Connecting rod caps (for CAL) Bolt M7 8 15 + 120_ 1.5 + 120_ 11 + 120_
Generator rotor Bolt M12 1 75 7.5 54
Timing chain tensioner Bolt M6 2 12 1.2 8.7
Timing chain tensioner cap bolt Bolt M6 1 7.0 0.7 5.1
Thermostat cover Bolt M6 2 12 1.2 8.7
Coolant hose joint Bolt M6 2 10 1.0 7.2
Water pump cover Bolt M6 2 10 1.0 7.2
Water pump Bolt M6 2 12 1.2 8.7
Thermo sensor Bolt M12 1 18 1.8 13
Coolant hose drain bolt
(water pump)
Bolt M6 1 10 1.0 7.2
Radiator and frame Bolt M6 2 7.0 0.7 5.1
Radiator stay and crankcase Bolt M6 1 10 1.0 7.2
Oil pump cover Bolt M6 3 12 1.2 8.7
Oil pump Bolt M6 3 12 1.2 8.7
Oil pan Bolt M6 12 12 1.2 8.7
Oil pan (center) Bolt M6 1 12 1.2 8.7
Oil cooler Bolt M20 1 63 6.3 46
Engine oil drain bolt Bolt M14 1 43 4.3 31
Oil filter union bolt Bolt M20 1 70 7.0 51
Oil filter – M20 1 17 1.7 12
Oil pump chain guide Bolt M6 2 12 1.2 8.7
Oil pipe Bolt M6 2 12 1.2 8.7
Throttle body joint Bolt M6 8 10 1.0 7.2
Air filter case cover Screw M5 6 1.2 0.12 0.9
Throttle body and throttle body joint Clamp M4 4 3.0 0.3 2.2
Throttle body and air filter case Clamp M5 4 3.0 0.3 2.2
Exhaust pipe and cylinder head Nut M8 8 20 2.0 15
Exhaust pipe and exhaust pipe stay Bolt M8 1 20 2.0 15
Catalyst pipe and catalyst pipe stay Bolt M8 1 20 2.0 15
Muffler joint Bolt M8 1 20 2.0 15
See NOTE 1
Catalyst joint Bolt M8 1 20 2.0 15 See NOTE 1
Exhaust stay and frame Bolt M8 1 34 3.4 25
Catalyst pipe stay and frame Bolt M8 1 20 2.0 15
Muffler stay and frame Bolt M8 2 20 2.0 15
