3-19
PERIODIC MAINTENANCE
EAS31428
CHECKING THE WHEELS
The following procedure applies to both of the
wheels.
1. Check:
• Wheel
Damage/out-of-round Replace.
EWA13260
Never attempt to make any repairs to the
wheel.
After a tire or wheel has been changed or re-
placed, always balance the wheel.
EAS31429
CHECKING THE TIRES
The following procedure applies to both of the
tires.
1. Check:
• Tire pressure
Out of specification Regulate.
EWA13181
• The tire pressure should only be checked
and regulated when the tire temperature
equals the ambient air temperature.
• The tire pressure and the suspension must
be adjusted according to the total weight
(including cargo, rider, passenger and ac-
cessories) and the anticipated riding
speed.
• Operation of an overloaded vehicle could
cause tire damage, an accident or an injury.
NEVER OVERLOAD THE VEHICLE.
WARNING
EWA13190
It is dangerous to ride with a worn-out tire.
When the tire tread reaches the wear limit,
replace the tire immediately.
2. Check:
• Tire surfaces
Damage/wear Replace the tire.
WARNING
EWA14090
After extensive tests, the tires listed below
have been approved by Yamaha Motor Co.,
Ltd. for this model. The front and rear tires
should always be by the same manufacturer
and of the same design. No guarantee con-
cerning handling characteristics can be giv-
en if a tire combination other than one
approved by Yamaha is used on this vehicle.
WARNING
EWA13210
New tires have a relatively low grip on the
road surface until they have been slightly
worn. Therefore, approximately 100 km
should be traveled at normal speed before
any high-speed riding is done.
For tires with a direction of rotation mark “1”:
• Install the tire with the mark pointing in the di-
rection of wheel rotation.
• Align the mark “2” with the valve installation
point.
Tire air pressure (measured on
cold tires)
1 person
Front
225 kPa (2.25 kgf/cm², 33 psi)
Rear
250 kPa (2.50 kgf/cm², 36 psi)
2 persons
Front
225 kPa (2.25 kgf/cm², 33 psi)
Rear
280 kPa (2.80 kgf/cm², 41 psi)
Maximum load
195 kg (430 lb) (XP560D)
197 kg (434 lb) (XP560E)
* Total weight of rider, passenger, cargo
and accessories
Wear limit (front)
1.5 mm (0.06 in) (XP560E)
1.6 mm (0.06 in) (XP560D)
Wear limit (rear)
1.5 mm (0.06 in) (XP560E)
1.6 mm (0.06 in) (XP560D)
Front tire
Size
120/70R15M/C 56H
Manufacturer/model
BRIDGESTONE/BATTLAX SCF
Rear tire
Size
160/60R15M/C 67H
Manufacturer/model
BRIDGESTONE/BATTLAX SCR
