Yamaha TMAX 2020 Service Manual

8-33
SIGNALING SYSTEM
EAS30501
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or an indicator light.
• The horn fails to sound.
• The fuel meter fails to operate.
• The speedometer fails to operate.
• The buzzer fails to sound.
• The V-belt replacement meter fails to operate.
• The ambient temperature meter fails to operate.
• The coolant temperature meter fails to operate.
• The oil change meter fails to operate.
TIP
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Storage box
3. Fuel tank
4. Footboards
5. Rear side cowling assembly (right)
1. Check the fuses.
(Main, signaling system, ABS mo-
tor, ABS solenoid, ABS ECU,
brake light and backup)
Refer to “CHECKING THE FUS-
ES” on page 8-93.
NG Replace the fuse(s).
OK
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-94.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
3. Check the ignition system relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the ignition system relay.
OK
4. Check the entire signaling sys-
tem’s wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
NG
Properly connect or replace the wire har-
ness.
OK
This circuit is OK.

Yamaha TMAX 2020 Specifications

General

Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Front Tyre	120/70R15M/C 56H
Rear Tyre	160/60R15M/C 67H
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	218 kg
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Suspension	Telescopic fork
Overall Height	1, 420mm
