Yamaha TMAX 2020 Service Manual

9-5
SYSTEM DIAGRAM
EAS20387
SYSTEM DIAGRAM
EAS32920
ECU CIRCUIT DIAGRAM
M
2. Battery
7. Electronic throttle
valve fuse
8. Ignition
system
relay
13. Ignition
fuse
14. Fuel
injection
system
fuse
15. Engine
stop
switch
19. Fuel
pump
16. Sidestand
relay
1. ECU (Engine
Control Unit)
18. Fuel
injection
system
relay
3. Main fuse
9. Signaling
system fuse
6. Front
brake light
switch
10. Rear
brake
light switch
4. Starter
relay
5. Starter
motor
21. Rectifier/regulator
A
B
20. Mode
switch
17. Sidestand
switch
27. Cruise control
power switch
29. Cruise control
setting switch (RES+)
28. Cruise control
setting switch (SET–)
25. Front
brake light
switch
26. Rear
brake light
switch
31. Crankshaft position sensor
32. Intake air pressure sensor
33. Coolant temperature sensor
34. Intake air temperature sensor
36. Lean angle sensor
35. O
2
sensor
30. Grip
cancel
switch
12. ON/start
switch
11. Starting
circuit cut-off
relay
24. Brake light fuse
25. Front brake light switch
26. Rear brake light switch
23. Brake light relay
22. Tail/brake light
40. Injector #1
41. Injector #2
44. Ignition coil
43. Throttle servo motor
42. Remote
control unit
B
A
29
26
32
41
96
95
34
66
83
82
67
98
72
76
68
86
84
5
70
88
25
17
9
10
18
64
15
16
1
102
33
65

Yamaha TMAX 2020 Specifications

General

Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Front Tyre	120/70R15M/C 56H
Rear Tyre	160/60R15M/C 67H
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	218 kg
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Suspension	Telescopic fork
Overall Height	1, 420mm
