Yamaha TMAX 2020 Service Manual

1-11
FEATURES
2. Push the “MENU” switch.
3. Use the select switch to highlight “YES”, and
then push the “MENU” switch. All items are
reset to factory preset or default settings.
TIP
The odometer, clock, maintenance counter item
“Oil” and maintenance counter item “V-Belt” will
not be reset.
To exit the setting mode
1. Use the select switch to highlight “Return”.
2. Push the “MENU” switch to exit the setting
mode and return to the standard display
mode.
EAS33377
CANCELING THE SIDESTAND ALARM
BEEPER
If the sidestand is lowered when the engine is
running, the engine will stop and the beeper will
sound to prevent you from forgetting to turn off
the vehicle power.
The sidestand alarm beeper can be set to not
activate.
Setting procedure
1. Set the engine stop switch “ ” “1” to “ ”.
2. While the smart key is on, press and hold
down the Parking/Unlock switch “ ” “1”
and the Power on/Starter switch “ ” “2” at
the same time.
TIP
The vehicle’s power turns on, but continue to
press and hold those switches.
3. After 8 seconds, a beeper sounds.
4. Release the Parking/Unlock switch “ ”
and Power on/Starter switch “ ”.
5. One more time, press and hold down the
Parking/Unlock switch “ ” and the Power
on/Starter switch “ ” at the same time.
6. After 2 seconds, a beeper sounds.
TIP
To return the sidestand alarm beeper to active,
do the same operation again.
1
1
2

Yamaha TMAX 2020 Specifications

General

Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Front Tyre	120/70R15M/C 56H
Rear Tyre	160/60R15M/C 67H
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	218 kg
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Suspension	Telescopic fork
Overall Height	1, 420mm
