Yamaha TMAX 2020 Service Manual

8-80
SMART KEY SYSTEM
EAS31535
SMART KEY SYSTEM EMERGENCY MODE
When the smart key is lost, damaged, or its battery has discharged, the vehicle can still be turned on
and the engine started. You will need a mechanical key and the smart key system identification number.
To operate the vehicle in emergency mode, carry out the following steps.
TIP
Emergency mode operation will be cancelled if the respective steps are not carried out within the time
set for each operation or if the OFF/LOCK switch is pushed.
1. Stop the vehicle in a safe place.
2. Unlock the seat by inserting the mechanical key into the lock located right side of body and turn it
counter clockwise.
3. Open the seat and check that the trunk light comes on.
4. Push the ON/start switch once.
5. Without completely shutting the seat, raise and lower it three times within 10 seconds.
TIP
Use the rear storage compartment light as a guide when raising and lowering the seat.
The smart key system indicator light “ ” on the speedometer will come on for three seconds to
indicate the transition to emergency mode.
6. After the smart key system indicator light “ ” goes off, use the Parking/Unlock switch to enter the
identification number. Refer to the following procedure on how to input the identification number.
1
1. Smart key system indicator light “ ”
123456
1
1. Identification number

Yamaha TMAX 2020 Specifications

General

Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Front Tyre	120/70R15M/C 56H
Rear Tyre	160/60R15M/C 67H
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	218 kg
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Suspension	Telescopic fork
Overall Height	1, 420mm
