Yamaha TMAX 2020 Service Manual

8-91
ELECTRICAL COMPONENTS
EAS30549
CHECKING THE SWITCHES
Check each switch for continuity with the digital circuit tester. If the continuity reading is incorrect, check
the wiring connections and if necessary, replace the switch.
TIP
Refer to “CHECKING THE SWITCHES” in “BASIC INFORMATION” (separate volume).
XP560E
G/Y Br
G/Y Br
Ch
N
R
L
Br/W Dg
W/L B/W
FREE
PUSH
W/RB/WW/G
UP
N
DOWN
B L/B B
PASS
HI
LO
Br
W/RW/G
L/B
BP
Br
G/Y
Dg
Ch
Br/W W/L
B/W
L
B
LB LB
L
B
Br/YR/W
Br/W R/B
Br
G/Y
L/G R
R
L/G
L/W
W/G B/W
B
Br P
PUSH
FREE
(B)
R/BR/W
RUN
OFF
L/W B
OFF
ON
Br/W Br/Y
OFF
ON
(B)
B/W W /G
FREE
PUSH
12
3
4
5
6
12
B
B
BB
7
13 14
89
10 11
15
1. Dimmer/pass switch
2. Horn switch
3. Menu switch
4. Select switch
5. Turn signal switch
6. Rear brake light switch
7. Sidestand switch
8. Engine stop switch
9. ON/start switch
10. Hazard switch
11. Mode switch
12. Front brake light switch
13. OFF/LOCK switch
14. Parking/Unlock switch
15. Storage box light switch

Yamaha TMAX 2020 Specifications

General

Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Front Tyre	120/70R15M/C 56H
Rear Tyre	160/60R15M/C 67H
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	218 kg
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Suspension	Telescopic fork
Overall Height	1, 420mm
