2-2 Art: 714364-00M Rev. Date: 02-Aug-12
Software
Battery
Compartment
The battery compartment is located at the display end of the analyzer next to
the laser barcode scanner window. The procedure for changing disposable and
rechargeable batteries can be found in the Routine Care of the Analyzer and
Downloader section of this manual.
Power
All analyzer functions are controlled by application software that can be updated
as additional tests and features are developed. Coefficients used to maintain the
accuracy of cartridge results over time are programmed into the analyzer via CLEW
software updates every six months. See under “Standardization and Calibration”
in section 3 of this manual for an explanation of CLEW.
There are two power options for the analyzer: disposable and rechargeable. The
analyzer is shipped with two disposable 9-volt lithium batteries and a battery carrier.
Lithium batteries may be ordered from i-STAT or obtained locally. ULTRALIFE
lithium batteries (ULTRALIFE Batteries, Inc., Newark, NY, USA) are recommended.
Only i-STAT rechargeable batteries may be used.
DESCRIPTION
Specifications
DIMENSIONS Width 7.68 cm (3.035 in.)
Length 23.48 cm (9.245 in.)
Depth 7.24 cm (2.85 in.)
WEIGHT With rechargeable battery 650 grams (22.9
oz.)
With disposable battery 635 grams (22.4 oz.)
POWER Two 9-volt lithium batteries, or rechargeable
battery.
CALIBRATION Factory: electronic, mechanical, thermal,
pressure
MEMORY/CLOCK BACKUP
POWER
Lithium Battery
DISPLAY Dot matrix supertwist liquid crystal
COMMUNICATION LINK Infrared light-emitting diode (LED)
OPERATING TEMPERATURE 16-30°C (61-86°F) for i-STAT cartridge testing
TRANSPORT
TEMPERATURE
-10-46°C (14-115°F)
RELATIVE HUMIDITY 90% (maximum) non-condensing
BAROMETRIC PRESSURE 300-850 mmHg
LASER SCANNER Complies with U.S. 21 CFR 1040.10 and
1040.11 except for deviations pursuant to
laser Notice No. 50, dated July 26, 2001.
EN 60825-1:1994 + A1:2002 + A2:2001
IEC 60825-1:1993 + A1:1997 + A2:2001
