Art: 714379-00F Rev. Date: 18-Jul-12 17-3
Removing and
Replacing the
Rechargeable
Battery
Wait until any test in progress is completed, and turn off the analyzer before
replacing the battery or the most recent set of results may be lost. Stored results
will not be lost when replacing the batteries.
STEP ACTION
1 Slide the battery compartment door off.
2 Tilt the analyzer slightly to slide out the rechargeable battery
pack.
3 The battery pack has two labels: one for orientation in the analyzer
and one for orientation in the Downloader/Recharger. With the
label with the analyzer facing up, and the electrical contact end of
the pack facing the analyzer, insert the pack into the analyzer as
shown on the label. If the pack is inserted incorrectly, the battery
door will not close.
4 Slide the battery compartment door back into place.
