Canon imagePRESS Lite C270 User Manual

Installation Procedure
Unpacking
■ Checking the Unpacking Space
The dimensions shown in the figure below are the minimum space required.
Thus it is desirable to secure more space for the work than shown in the figure below.
1. The dimensions of the host machine and transportation container are as shown in the figure below.
Secure the space for unpacking before work.
1,041 mm
1,150 mm
1,465 mm
2. The following space is needed when unloading from the pallet.
• [1] Pallet
• [2] Slope Plate
• [3] Host Machine
[1] [2] [3]
2750 mm
2. Host Machine
17
