7. Connect the lattice connector of the Paper Deck to the host machine and then fix the cable with the wire saddle.
• 1 Connector
• 1 Wire Saddle
8. Turn ON the host machine.
Checking after Installation
â– Installation Procedure
1. Following disposal parts are remained after the installation procedure.
[1]
Cable Protection Bushing 1pc.
[2] Screw (TP; M4x4) 2pcs.
[3] Power Supply Label 1pc.
[4] Blindfold Cover 1pc.
[5] Blindfold Seal 4pcs.
[6] Blindfold Plate 1pc.
5. Paper Feed Options
379
