*[6] Cable protection bushing is not used for the installation.
<Others>
Including guides
Installation Procedure
■ Preparation of the Paper Deck Unit
1. Turn OFF the main power switch of the host machine.
2. Disconnect the lattice connector from the host machine and then release the cable from the wire saddle.
• 1 Wire Saddle
• 1 Connector
1x1x
3. Pull the release lever and then withdraw the Paper Deck Unit until it stops.
5. Paper Feed Options
365
