4. Initializing SSD
<In case of SST>
1. Start the host machine with download mode in safe mode.
2. Start the SST.
3. Select the model. Then, select [Single] and click [Start].
4. Click [Format HDD].
5. Select [All], and click [Start].
6. Click [Execute Format].
7. The Format is executed.
8. Select [Shutdown/Restart], and click [Shutdown].
9. Click [OK]
10. The power of the host machine is turned OFF.
11. Terminate the SST.
12. Disconnect the Cross Ethernet Cable from the machine, and connect the user's network cable to the machine.
<In case of USB flash drive>
1. Connect the USB flash drive to the PC.
2. Start up SST, and click the USB icon displayed in the target selection screen.
3. Select the drive, the model series, and the version to be written to the USB flash drive, and click [Confirm].
4. Click [Start], and after the version has been written to the USB flash drive, click [OK] and then remove the USB flash
drive.
5. Terminate the SST.
6. Connect the USB flash drive to the host machine, and start the host machine with download mode in safe mode.
7. When the USB menu is displayed, press keys on the Control Panel in the order shown below.
• [4]: Clear/Format
• [1]: Disk Format
• [0]: OK
• Press any keys.
• [C]: Return to menu
• [Reset] : Start shutdown sequence
• [0]: OK (The power of the host machine is turned OFF automatically.)
8. Remove the USB flash drive.
9. Turn ON the main power switch.
■ Executing Auto Gradation Adjustment
When the high-capacity SSD is installed, the machine initializes its SSD, resetting the data used for auto gradation correction.
Therefore, execute full adjustment of auto gradation adjustment after installing the high-capacity SSD to enable proper images
to be output.
■ Execution of the Minimum Installation Work
Be sure to execute the minimum installation work in accordance with the Setup Guide because SSD is initialized when the high-
capacity SSD is installed.
[TYPE-2] Memory Mirroring Kit
CAUTION:
• When using the memory mirroring function, be sure to install 2 SSDs of the same capacity.
• When installing a memory mirroring kit on a large-capacity SSD, refer to [TYPE -1] Optional SSD (1TB) > Installation
procedure before installing the mirroring.
4. Host Machine Options
