2. If a message prompting the user to update the version appears, press [Update] to automatically update the version
of this Equipment.
NOTE:
If [Skip] is selected, a message prompting the user to update the version will appear every time the Host Machine is started. In
the service mode ( Level 2 ) shown below, it is possible to set not to display the message.
( Level2 ) COPIER > OPTION > FNC-SW > VER-CHNG
3. Check the operation such as paper feed and punch operation to make sure that problems such as a jam or
malfunction do not occur.
NOTE:
If the punch hole position of this Equipment needs to be adjusted, go to the "Checking and Adjusting the Punch Hole Position".
Adjusting the Output Level of the Punch Waste Full Sensor
After installing this Equipment, adjust the output level of the Punch Waste Full Sensor as follows.
1. Select the following item in the Service Mode and then press the OK button on the screen.
Service Mode (Level1) > SORTER > FUNCTION > FN-SENS2
2. When completing the output level adjustment successfully, the "OK" is indicated on the screen.
NOTE:
If the "NG" is indicated on the screen at the step 2, retry the adjustment by repeating the step 1. If the "NG" is indicated after
retrying the adjustment, check whether there is not the malfunction in attachments and connections of the Punch Waste Full Sensor
Unit and the surrounding area.
6. Paper Output Options
818
