imagePRESS Server M20
The IP addresses for communication between the host machine and
equipment are set automatically
1. Turn ON the main power switch of the host machine.
2. Set the value in the following service mode to "3".
COPIER > OPTION >INT-FACE > IMG-CONT
3. Exit from Service Mode.
4. Turn OFF the main power switch of the host machine.
Check When Connecting the Power Plug to an Outlet
1. When connecting the power plug of this equipment to an outlet, be sure to use an outlet of a system different from that of
the host machine.
2. Be sure to install this equipment near an outlet so that the power plug can be disconnected right away in case of emergency,
and do not put anything around the power plug.
Checking the Contents
9.7 mm
22 mm
Stepped Screw;
M4x9
2x
Stepped Screw;
M3x9.6
2x
Toothed Washer Screw
(Binding; M4x8)
4x
Toothed Washer
4x
2x
TP; M3x8
4x
TP; M3x6
2x
1x
1x
1x
1x 1x
1x
1x
2x
2x
* Power Cord: The connector has a different shape depending on locations. 2 are packaged in the products for EUR/1 is packaged
in the products for USA. Use the correct power cord to mach the location/area of installation.
Make sure not to leave unused power cord at the site.
<Others>
• Including guides
4. Host Machine Options
301
