Checking the Contents
[1] Punch Unit x1 [3] Punch Waste
Full Sensor Unit x1
[2] Punch Waste Tray x1
[5] Punch Unit Fixing Pin
Holder x1
[8] Relay Harness x1
[4] Punch Unit
Open/ Close Guide x1
[7] Punch Unit
à ‰à ‰Positioning Guide x1
[6] Punch Unit Fixing Pin
x1
[9] Face Seal x1
[10] Rear Inner Cover
(small) x1
[11] Screw
(W Sems ; M3x6) x1
[12] Punch Front Cover x1
• Part [12] is not used for installation.
<Others>
Other bundled items such as Installation Procedure, leaflets, etc.
Installation Procedure
CAUTION:
Make sure that the main power switch of the host machine is turned off and the power plug is disconnected from the outlet.
