Turning on the main power supply
CAUTION:
Since the automatic adjustment of the ADF reading position is executed when the main power is turned on for the
first time, remove all on the copyboard glass and then close the ADF.
1. Remove the protection sheet on the control panel.
2. Turn ON the main power switch.
CAUTION:
When the main power is turned ON, the ITB neutral position adjustment (service mode > COPIER > FUNCTION > INSTALL
> INIT-ITB) is automatically executed. Therefore, it is not necessary to manually execute the service mode.
• Do not open the cover or turn OFF the power during the automatic adjustment.
• Since color displacement correction is included in this adjustment, it is not necessary to separately execute it in service
mode.
3. If a message prompting the user to update the version appears, press [Update] to automatically update the version
of this equipment.
NOTE:
If [Skip] is selected, a message prompting the user to update the version will appear every time the Main machine is started. In
the service mode (Lv.2) shown below, it is possible to set not to display the message prompting the user to update the version.
COPIER > OPTION > BODY > VER-CHNG
Installing the Toner Container
1. Open the Front Upper Cover, only after the toner container replacement screen has appeared on UI.
2. The Replacement Cover opens automatically.
NOTE:
Disregard the screen that includes the message "Replace the toner cartridge.", as the Toner Containers are not yet loaded at the
time of initial installation.
3. Shake the Toner Container approx. 10 times.
4. Rotate and remove the Protection Cap of the Toner Container.
5. Set a new Toner Container and close the Replacement Cover.
6. Repeat steps 3 to 5 to install the Toner Containers of other colors in the same manner.
CAUTION:
Be sure that the color is correct.
7. Close the Front Upper Cover.
NOTE:
Toner supply starts automatically when the Front Upper Cover is closed.
2. Host Machine
71
