Stack Bypass Alignment Tray-D1
Points to Note at Installation
Although pictures or illustrations used for explanationmay differ from the actual things, the procedure is the same.
CAUTION:
• Before starting the installation work, check that the user is not making a print from the Multi-purpose Tray Pickup Tray.
• When installing the Long Sheet Tray and this kit at the same time, install the Long Sheet Tray before performing
"Procedure after Work" in this document.
Checking the Contents
1x 1x
1x
Stepped Screw
; M3x13.2
1x
TP Round End
; M4x6
2x
Installation Outline Drawing
5. Paper Feed Options
522
