Checking the Contents
NOTE:
• A separate optional power cord must be provided for this equipment installation.
• [7]: Not used
[1] Two-Knife Booklet
Trimmer X 1
[2] Bolt Cap X 2 [3] Wire Holder X 2
[5] Screws for Locking
the Conveyor
(RS Tightening Round
End; M4 x 8 mm) X 2
[6] Screws for Locking
the Two-Knife Booklet
Trimmer (M5 x 10 mm) X 2
[7] Ground wire X 1
[4] Trimming Booklet
Waste Box X 1
Installation Procedure
â– Preparing the Two-Knife Booklet Trimmer
1. Open the Top Cover [3], remove the 2 screws (RS Tightening Round End) [2] of the Front Cover [1], and then remove
the Front Cover. Close the Top Cover [3].
6. Paper Output Options
899
To Next Page
