4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.9 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 121
4.9.4 Acyclic data
The following acyclical objects can be read via the PKE-SWD-32 in addition to
the cyclical input and output bytes.
The required object is addressed with parameters “ID” and “Index”. The
input address of the SmartWire-DT module with which communication is to
be established is set with parameter “ID”. Meanwhile, the "Index" parameter
specifies the address of the actual object. The first object is assigned num-
ber 1, the second 2 etc. For the PKE-SWD-32, object 1 supplies current value
“I-REL”.
Object 1 [Index 1]:
Byte 0:
Object 2 [Index 2]:
Byte 0:
76543210
I-REL I-REL I-REL I-REL I-REL I-REL I-REL I-REL
Data byte
Data bit Designation Description Notes
0 0-7 I-REL Motor current [%] Section 4.9.1.6, "Motor
current [%] (I-REL)", page
113
76543210
TH TH TH TH TH TH TH TH
Data byte
Data bit Designation Description Notes
0 0-7 TH Thermal motor
image [%]
Section
4.9.1.7, "Thermal motor
image [TH]", page 113
