Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.9 Digital module EU5E-SWD-4D4D-R
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 39
Fieldbus EtherCAT
Please note the general information for configuring parameters
￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page
247, particularly
￫ Section , „Device options“, page 247.
Device index: sub-index 22
Parameter data length: 0x02
Structure of parameter byte 1: retentive behavior
2.9.7 Programming
The module has two input bytes and one output byte at its disposal.
2.9.7.1 Input points
Byte 0: status SmartWire-DT
Bit Parameter Configuration Default
0 Retentive behavior
Output Q0
1: Output Q0 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q0 will be reset
0: Output Q0 will be reset
1
Retentive behavior
Output Q1
1: Output Q1 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q1 will be reset
0: Output Q1 will be reset
2
Retentive behavior
Output Q2
1: Output Q2 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q2 will be reset
0: Output Q2 will be reset
3
Retentive behavior
Output Q3
1: Output Q3 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q3 will be reset
0: Output Q3 will be reset
4-7
reserved 0 0
Bit Parameter Configuration Default
0 Retentive behavior
Output Q0
1: Output Q0 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q0 will be reset
0: Output Q0 will be reset
1
Retentive behavior
Output Q1
1: Output Q1 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q1 will be reset
0: Output Q1 will be reset
2
Retentive behavior
Output Q2
1: Output Q2 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q2 will be reset
0: Output Q2 will be reset
3
Retentive behavior
Output Q3
1: Output Q3 will retain its state even if there is
a loss of communication or the controller stops
0: Output Q3 will be reset
0: Output Q3 will be reset
4-7
reserved 0 0
76543210
SUBST PRSNT – DIAG – – – –
