Eaton SmartWire-DT SWD Series User Manual

3 Switching on DIL-SWD-32-001, DIL-SWD-32-002 contactors
3.1 Introduction
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 65
3 Switching on DIL-SWD-32-001, DIL-SWD-32-002 contactors
3.1 Introduction
The SmartWire-DT modules DIL-SWD-32-001 and DIL-SWD-32-002 for DILM
are snapped directly onto either a contactor type DILM7 to DILM38, a DILA
contactor relay or an MSC motor starter. It is for the purpose of driving a con-
tactor or a motor starter via a programmable logic controller and acquiring the
feedback.
The interoperability requirements for these SmartWire-DT modules are
described in ￫ Section 13.6, „SWD module interoperability requirements“,
page 259.
ATTENTION
No additional auxiliary contact block can be snapped onto the
contactor. The auxiliary switches integrated into the contactor
can be used, for example, as safety locking devices.
ATTENTION
In addition to the basic devices (contactors, motor starter combi-
nations, etc.) described in the individual sections, The Smart-
Wire Device Technology (SmartWire-DT) function elements
listed in this manual can also be combined with equivalent
Eaton basic devices that use the Eaton catalog number as part
number.
For a reference table, see the Appendix on Page 258.
