3 Switching on DIL-SWD-32-001, DIL-SWD-32-002 contactors
3.3 Engineering
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 67
Adjustment of the SmartWire-DT module for DILM to the respective contac-
tor size is performed via the adjusting slide for the contactor size â‘¥.
3.3 Engineering
SmartWire-DT modules DIL-SWD-32-001 and DIL-SWD-32-002 can be com-
bined with circuit breakers DILM7 to DILM38. This allows the use of motor
starters consisting of a motor-protective circuit-breaker PKZ and a contactor
DILM with the SmartWire-DT system.
With contactor combinations a SmartWire-DT module for DILM is required
for each contactor.
Table 3: Combination options
As well as with contactors the SmartWire-DT module for DILM can also be
combined with all DILA contactor relays.
The contactor´s power supply is directly supplied via the SmartWire-DT con-
nection cable. The contactor coils have the following power consumptions
with a voltage of 24 V DC:
Table 4: Power consumptions of the contactor coils with a voltage of 24 V DC
Application
Number of SmartWire-DT modules for DILM
DILM contactor 1
Motor starter MSC
DOL starter (PKZ and DILM) 1
Reversing starter
2
Reversing combination
2
ï¿«
Contactors with a rated operational current greater than 38 A
can be integrated into the SmartWire-DT system with a DILA as
a coupling relay or SmartWire-DT I/O module.
Contactor Pick-up power Pick-up current
with 24 V DC
Sealing power Holding current
with 24 V DC
[W] [mA] [W] [mA]
DILA, DILM7 3 125 3 125
DILM9 – DILM15
4.5 188 4.5 188
DILM17 – DILM38
12 500 0.5 21
