7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
162 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
7.2.6 Device Status
The individual SmartWire-DT modules indicate their device status with the
aid of a diagnosis LED.
Table 34: Diagnostic messages of the SmartWire-DT status LED
7.2.7 Parameterization
Depending on the coordinator being used, the module's parameters will
need to be configured in the programming system or in the SWD-Assist plan-
ning and commissioning program.
7.2.8 Fieldbus-specific characteristics
Field bus Ethercat
Please note the general information for configuring parameters
Chapter 12 “Using SWD modules with the EtherCAT eld bus”, page
247.
7.2.9 Programming
The various function elements have specific input/output information that is
processed in the programming system. The meaning and scope are
described in the following.
7.2.9.1 M22-SWD-K11
The function element has one input byte at its disposal.
Input points
Byte 0:
Designation Color State Message
SWD Green Continuous light Device is operating fault-free.
flashing (1 Hz) addressing process in progress
after gateway power On
after actuation of the configuration
button on the gateway
Module not in current configuration
invalid type
flashing (3 Hz) Device reports a diagnostics.( Section
"7.3.9 Programming", sub-point “Diagnos-
tics”.)
NO1
NC1
