Eaton SmartWire-DT SWD Series User Manual

8 SL4-SWD and SL7-SWD base modules for signal towers
8.7 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 211
8.6.1 Fieldbus-specific characteristics
Field bus Ethercat
Please note the general information for configuring parameters
￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page
247.
8.7 Programming
The module has one input byte.
8.7.1 Input points
Byte 0:
8.7.2 Outputs
Byte 0:
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
76543210
– – – Q4Q3Q2Q1Q0
Bit
Designation Description
0 Q0 Turns on light module Q0
1
Q1 Turns on light module Q1
2
Q2 Turns on light module Q2
3
Q3 Turns on light module Q3
4
Q4 Turns on light module Q4
