Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
268 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.7.3 I/O modules, analog
EU5E-SWD-4AX EU5E-SWD-2A2A EU5E-SWD-4PT
EU5E-SWD-4PT-2
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm
35 x 90 x 101 35 x 90 x 101 35 x 90 x 101
Weight kg
0.1 0.1 0.1
Mounting
DIN-rail IEC/EN 60715, 35 mm
Mounting position
vertical vertical vertical
Ambient mechanical conditions
Degree of protection (IEC/EN 60529, EN50178,
VBG 4)
IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 - 8.4 5 - 8.4 5 - 8.4
Constant acceleration, 1 g Hz
8.4 - 150 8.4 - 150 8.4 - 150
Mechanical shock resistance (IEC/EN
60068-2-27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm
50 50 50
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II II
pollution degree
2 2 2
Electrostatic discharge
(IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8
Contact discharge (Level 2) kV
4 4 4
Electromagnetic fields
(IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10 10 10
1.4 - 2 GHz V/m
3 3 3
2 - 2.7 GHz V/m
1 1 1
Radio interference suppression (SmartWire-DT)
EN55011 Class A EN55011 Class A EN55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2
Signal cables kV
2 2 2
SmartWire-DT cables kV
2 2 2
Surge (IEC/EN 61131-2:2008, Level 1)
Supply cables 1 kV Supply cables 1 kV Supply cables 1 kV
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10 10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-
2)
°C -25 - +55 -25 - +55 -25 - +55
Condensation
Must be prevented with suitable measures
