4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.1 Introduction
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 85
4 PKE-SWD-32, interface for motor-starter combination with PKE
PKE12/32
4.1 Introduction
The PKE-SWD-32 SmartWire-DT module is used to enable a PLC to control a
motor-starter combination based on the PKE motor protective circuit breaker,
and to receive the signals of the contactor and those of the PKE motor pro-
tective circuit breaker. The PKE-SWD-32 is snap fitted directly to a DILM7 to
DILM32 contactor and connected to the trip block of the PKE via a data
cable.
The interoperability requirements for these SmartWire-DT modules are
described in ￫ Section 13.6, "SWD module interoperability requirements",
page 259.
￫
Operation and installation of electronic motor-protective circuit-
breaker PKE are described in document MN03402004Z-DE (for-
mer designation AWB1210-1631).
ACHTUNG
The communication connection of the PKE 12/32 is only possi-
ble when using PKE trip blocks of part no. “Advanced”, i.e. PKE-
XTUA-….
ACHTUNG
No additional auxiliary contact block can be snapped onto the
contactor. The auxiliary switches integrated into the contactor
can be used, for example, as safety locking devices.
ACHTUNG
In addition to the basic devices (contactors, motor starter combi-
nations, etc.) described in the individual sections, The Smart-
Wire Device Technology (SmartWire-DT) function elements
listed in this manual can also be combined with equivalent
Eaton basic devices that use the Eaton catalog number as part
number. For a reference table, see the Appendix on Page 258.
