Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 281
13.7.10 SWD-Basemodules for signal towers
SWD base modules for signal towers are meant exclusively for use with
SmartWire-DT systems.
SL4-SWD SL7-SWD
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm
80 x 157 x 80 80 x 192 x 80
Weight kg
0.204 0.293
Mounting
srew fixing
Mounting position
Any
Ambient mechanical conditions
Degree of protection (IEC/EN 60529,
EN50178, VBG 4)
IP66
Can be used in environments with
pollution degree
2
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 – 8.4
Constant acceleration, 1 g Hz
8.4 – 150
Mechanical shock resistance (IEC/EN 60068-2-
27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
3 per shaft, pos. and neg.
Drop to IEC/EN 60068-2-31 Drop
height
mm
100
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3
Dielectric strength
Overvoltage category II
pollution degree
2
Measurement of the clearance and creepage
distance
EN 50178, UL 508, CSA C22.2, No. 142
Dielectric strength
EN 50178_x
Electromagnetic compatibility (EMC)
Electrostatic discharge
(IEC/EN 61131-2:2008)
Performance criterion B
Air discharge (Level 3) kV
8
Contact discharge (Level 2) kV
4
Electromagnetic fields
(IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10
1.4 - 2 GHz V/m
10
2 - 2.7 GHz V/m
10
Radio interference suppression (SmartWire-DT) EN55011
Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2
Signal cables kV
2
SmartWire-DT cables kV
1
