5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.1 Introduction
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 123
5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.1 Introduction
SmartWire-DT module PKE-SWD actuates motor-protective circuit-breaker
PKE through a PLC and to receive data from the electronic motor-protective
circuit-breaker. The PKE-SWD is connected directly to motor-protective cir-
cuit-breakers PKE12, PKE32 and PKE65.
The interoperability requirements for these SmartWire-DT modules are
described in ￫ Section 13.6, „SWD module interoperability requirements“,
page 259.
￫
Operation and installation of electronic motor-protective circuit-
breaker PKE are described in document MN03402004Z-DE (for-
mer designation AWB1210-1631).
ATTENTION
The PKE-SWD can be combined only with PKE trip blocks of
type “Advanced” (PKE-XTU(W)A).
ATTENTION
The PKE-SWD can not be combined with motor-starter combi-
nations MSC-DEA up to 32A. Motor-starter combinations MSC-
DEA can be connected to the SmartWire-DT system with
SmartWire-DT module PKE-SWD-32.
￫
In addition to the basic devices (contactors, motor-starter com-
binations, etc.) described in the individual sections, the function
elements of the SmartWire-DT system listed in this manual can
also be combined with equivalent Eaton basic devices that use
the Eaton catalog number as part number. For a reference table,
see the appendix on Page 258.
