Eaton SmartWire-DT SWD Series User Manual

1 EU5C-SWD-PF1-1, EU5C-SWD-PF2-1 power modules
1.2 EU5C-SWD-PF1-1
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 17
Figure 2: Terminal capacities
• flexible: cross-section 0.25 mm² to 1.5 mm², with the ferrule (minimum
length 8 mm)
• solid: 0.14 to 1.5 mm²
1.2.5 Diagnostics
The device does not report a diagnosis
￫
Information on the cable protection is provided on Page 20
24V
0V
POW
AUX
24V
0V
AUX
24V
0V
24 V DC
0 V
F1 F2 F2
