Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.1 Introduction
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 139
6 PKE-SWD-CP,
Connection for circuit-breaker PKE
6.1 Introduction
The purpose of the PKE-SWD-CP SmartWire-DT module is to control PKE
motor-protective circuit-breakers, used in combination with PKE-
XTU(W)ACP-… trip blocks, as communications-capable circuit-breakers via a
programmable logic controller and to acquire data from PKE electronic motor-
protective circuit-breakers.
The PKE-SWD-CP is connected directly to motor-protective circuit-breakers
PKE32 or PKE65.
The interoperability requirements for these SmartWire-DT modules are
described in ￫ Section 13.6, „SWD module interoperability requirements“,
page 259.
ATTENTION
PKE-SWD-CP modules can only be combined with the following
PKE trip blocks:
• PKE-XTUACP-36
• PKE-XTUWA-CP-36
• PKE-XTUACP-65
￫
In addition to the basic devices (contactors, motor-starter com-
binations, etc.) described in the individual sections, the function
elements of the SmartWire-DT system listed in this manual can
also be combined with equivalent Eaton basic devices that use
the Eaton catalog number as part number.For a reference table,
see the Appendix Page 253.
