Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.2 Power-/current consumption of the SWD stations on U
AUX
254 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.2 Power-/current consumption of the SWD stations on U
AUX
SL4-SWD 171311 26 –
SL7-SWD 171459
26 –
SWD4-RC8-10 116020
17 –
Catalog number Article no. Current consumption
[mA]
Notes
DIL-SWD-32-…
Pick-up power
for DILMA,DILM7 W 3
at DILM7 – DILM15 W
4.5
at DILM17 – DILM38 W
12
Pick-up current
at DILM7 – DILM9 mA 125
at DILM12 – DILM15 mA
188
at DILM17 – DILM38 mA
500
Sealing power
for DILMA, DILM7 W 3
at DILM7 – DILM15 W
4.5
at DILM17 – DILM38 W
0.5
Holding current
for DILMA, DILM7 mA 125
at DILM7 – DILM15 mA
188
at DILM17 – DILM38 mA
21
EMS-...-SWD-ADP
Current
Switch on mA 120
Operation mA
60
NZM-XSWD-704
Current
With active remote operator mA 300
With inactive remote operator mA
100
SL4-SWD SL7-SWD
Current
With an LED light module
Continuous light mA 33 54
Beacon mA
36 58
Strobe light mA
65 135
With an LM high-power LED
Continuous light mA – 200
Beacon mA
– 265
Strobe light mA
– 265
With a filament lamp light module mA
167 292
With an acoustic module
Continuous or pulsed tone mA 39 92
Continuous or pulsed tone, 8 types of mA
– 115
