Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.9 Digital module EU5E-SWD-4D4D-R
38 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
2.9.4 Installation
▶ Connect the sensors to the corresponding inputs I0 to I3.
▶ Connect the reference potential 0 V DC to connection 0V.
▶ Connect the actuators to the corresponding output Q0 to Q3.
▶ Connect the 24 V DC supply voltage for the outputs to the 24 V connec-
tion terminal
▶ Connect the module to the SmartWire-DT network.
2.9.5 Parameterization
Depending on the coordinator being used, the module's parameters will
need to be configured in the programming system or in the SWD-Assist plan-
ning and commissioning program.
Retentive behavior outputs Q0..Q3
The selection for this parameter defines the behavior of the outputs in the
event that:
• Communication between the SmartWire-DT coordinator (e.g., gateway)
and the higher-level controller is interrupted
or
• The controller switches to a stop
Normally, all outputs will be switched off in these cases.
Details to retentive behavior ￫ Section 2.9.3, „Engineering“, page 36.
2.9.6 Fieldbus-specific characteristics
Field bus CANopen
The module is parameterized through its associated parameter byte in the
control configurator.
For values other than the default, change these values as shown below.
Structure of parameter byte 1: retentive behavior
Parameter Setting options Basic Setting
Retentive behavior
output Q0
• Output Q0 will retain its state even if there is a loss
of communication or the controller stops
• Output Q0 will be reset
Output Q0 will be reset
Retentive behavior
output Q1
• Output Q1 will retain its state even if there is a loss
of communication or the controller stops
• Output Q1 will be reset
Output Q1 will be reset
Retentive behavior
output Q2
• Output Q2 will retain its state even if there is a loss
of communication or the controller stops
• Output Q2 will be reset
Output Q2 will be reset
Retentive behavior
output Q3
• Output Q3 will retain its state even if there is a loss
of communication or the controller stops
• Output Q3 will be reset
Output Q3 will be reset
