Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
262 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.7 Technical data
13.7.1 Power feeder module
EU5C-SWD-PF1-1 EU5C-SWD-PF2-1
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm
35 x 90 x 124
Weight kg
0.11 0.17
Mounting
DIN-rail IEC/EN 60715, 35 mm
Mounting position
vertical
Ambient mechanical conditions
Degree of protection (IEC/EN 60529,
EN50178, VBG 4)
IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude of 3.5 mm Hz 5 - 8.4 5 - 8.4
Constant acceleration 1 g Hz
8.4 - 150 8.4 - 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal: 15 g/11 ms
Impact
resis-
tances
9 9
Drop to IEC/EN 60068-2-31 Drop height mm
50 50
Free fall,
packaged (IEC/EN 60068-2-32)
m
0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II
pollution degree
2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8
Contact discharge (Level 2) kV
4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10 10
1.4 - 2 GHz V/m
3 3
2 - 2.7 GHz V/m
1 1
Radio interference suppression (SmartWire-DT)
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2
CAN/DP bus cable kV
– –
SmartWire-DT cables kV
1 1
Surge (IEC/EN 61131-2:2008, Level 1)
Supply cables/CAN/DP bus cable Supply cables 0.5 kV
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C –25 - +55 –25 - +55
