Eaton SmartWire-DT SWD Series - Programming

2 I/O modules EU5E-SWD…
2.13 Analog module EU5E-SWD-2A2A
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 57
Fieldbus EtherCAT
Please note the general information for configuring parameters
￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page
247, particularly
￫ Section , „Device options“, page 247.
Defining the sensor type and the measuring settings:
Device index: sub-index 22
Parameter data length: 0x02
Structure of parameter byte 1:
2.13.7 Programming
The module has an input byte for SmartWire-DT status, two words for the
analog inputs and two output words for the analog outputs.
Bit Function Configuration
0 Sensor selection
Input 1
0 = Voltage
1 = Current
1
Sensor selection
Input 2
0 = Voltage
1 = Current
2
Sensor selection
Input 3
0 = Voltage
1 = Current
3
Sensor selection
Input 4
0 = Voltage
1 = Current
4 , 5
Reading refresh rate Bit 5
0
0
1
1
Bit 4
0
1
0
1
= 20 ms
= 100 ms
= 200 ms
= 500 ms
6
Mean value 0 = off
1 = on
7
reserved 0
Bold values indicate the default settings.
