Eaton SmartWire-DT SWD Series User Manual

3 Switching on DIL-SWD-32-001, DIL-SWD-32-002 contactors
3.8 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 83
3.8.1.3 Diagnostics
The module does not report a diagnosis.
3.8.2 DIL-SWD-32-002
The function element has one input byte and one output byte at its disposal.
3.8.2.1 Input points
Byte 0:
76543210
–––––––Q0
Bit
Designation Description
0 Q0 Contactor actuation
1
Not used –
2
Not used –
3
Not used –
4
Not used –
5
Not used –
6
Not used –
7
Not used –
76543210
SUBST PRSNT – DIAG M I
(X1-X0)
I0 (X1-
X2)
C
Bit
Designation Description
0 C = Contactor 0: contactor not tripped
1: contactor tripped
1
I0 (X1-X2) 0: Auxiliary contact for X1-X2 opened
1: Auxiliary contact for X1-X2 closed
The meaning depends on the auxiliary switch used.
2
I1 (X1-X0) 0: Auxiliary contact for X1-X0 opened
1: Auxiliary contact for X1-X0 closed
The meaning depends on the auxiliary switch used.
3
M = Manual 0: Automatic
1: Manual mode
4
DIAG 0: no diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
