Eaton SmartWire-DT SWD Series User Manual

10 SmartWire-DT universal module M22-SWD-NOP and M22-SWD-NOP-C
10.2 Surface mounting
220 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
10.2.1 Front mounting
Front-fixing universal modules M22-SWD are used as placeholders for pilot
devices and contactors, motor-protective circuit-breakers in consoles, control
panel doors or in control panels.
Figure 80: RMQ module as carrier element of a universal module for front mounting
10.2.1.1 Advantages
• Good mechanical adaptability.
• Can be mounted directly on top-hat rail.
• Telescopic clip for height compensation, for example to the motor-starter
combinations.
10.2.2 Base mounting
Base-fixing universal modules M22-SWD are used as placeholders in combi-
nation with surface mounting enclosures M22-I….
M22-(C)K…
M22-(C)K…
M22-SWD-K11…
M22-SWD-LED…
M22-SWD-NOP
14 36 25
M22-SWD-K22…
M22-(C)K…
14
36 25
M22-SWD-NOP
M22-SWD-NOP
SWD-8SF2-5
SWD4-…LF…
