6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 145
6.10 Programming
6.10.1 PKE-SWD-CP cyclic data
The PKE-SWD-CP has a maximum of eight input bytes and one output byte.
6.10.1.1 Input points
Byte 0:
Byte 1:
￫
The number of cyclical input bytes can be adjusted by means of
different data profiles of the module (￫ Section 6.10.2, „Data
profiles“, page 152).
76543210
SUBST PRSNT – F – – STAT –
Data bit
Designation Description
0 Not used -
1
STAT Contactor state PKE
0: PKE switched off
1: PKE Powered up
2
Not used -
3
Not used -
4
F = Failure 0: No diagnostic alarm
1: Module signals diagnostics
5
Not used -
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
76543210
– TRIPR TRIPR TRIPR Ir Ir Ir Ir
Data bit
Designation Description Notes
0-3 Ir Set value I
r
￫ Section 6.10.1.4, „Set value (Ir)“,
page 148
4-6
TRIPR =
Trip reason
Trip Reason ￫ Section 6.10.1.5, „Dierential trip
indication (TRIPR)“, page 149
7
Not used - -
